DBF-1000 Automatic Inflatable Film Sealing Machine
DBF-1000 automatic inflatable film sealing machine continuously seals plastic bags while filling air inside. Adjustable sealing speed 0–12m/min, seal width 6–12mm, steel date printing function, max conveyor load 5kg. Ideal for snacks, fried food that needs air cushion protection against extrusion damage.
Description
Pain Points for Inflatable Bag Packaging
Snack and fried food packaging often get crushed during transportation. Ordinary sealers only seal bags without air inflation, finished products easily deform and break. Many small packaging lines want simple inline air filling + sealing together, plus date marking. Our DBF-1000 automatic inflatable film sealing machine solves this problem. It integrates air inflation, continuous sealing and steel stamp printing in one machine. The air inside the pouch forms a cushion to protect fragile food from squeeze damage.
Suitable Industries & Bag Types
Industries: Snack food, fried food, puffed food, nuts
Bags: PE plastic film bags, composite thin film pouches
Machine Core Advantages
- Integrated air inflation + continuous sealing: fills air while sealing, forms air cushion to protect fragile products
- Adjustable sealing width 6–12mm, flexible for different thin film bags
- Built-in steel stamp printing, print production date or batch number on pouch while sealing
- Wide temperature control range 0–300℃, adapts various plastic thin film materials
- Compact tabletop design, light weight (39kg), easy to move and install in small workshop
- Continuous conveyor operation, adjustable speed 0–12m/min, match low & medium production throughput
Technical Parameters
| Item | Specification |
|---|---|
| Model | DBF-1000 |
| Power Supply | 110/220V 50-60Hz |
| Total Power | 750W |
| Sealing Speed | 0–12m/min |
| Sealing Width | 6–12mm |
| Temperature Range | 0–300℃ |
| Max Conveyor Load | 5kgs |
| Printing Type | Steel stamp printing |
| Net Weight | 39kg |
| Overall Dimension(L×W×H) | 1060 × 640 × 970mm |
Frequently Asked Questions
Q1: What is the main function of DBF-1000 inflatable sealer?
A: It can inflate air into plastic bags while continuously sealing, keep the pouch inflated to protect puffed snacks and fried food from being crushed in transit.
A: It can inflate air into plastic bags while continuously sealing, keep the pouch inflated to protect puffed snacks and fried food from being crushed in transit.
Q2: Can this machine print batch or date code?
A: Yes, it supports steel stamp printing, mark production date and batch number on bags during sealing.
A: Yes, it supports steel stamp printing, mark production date and batch number on bags during sealing.
Q3: What is the maximum load on the conveyor?
A: Max conveyor load 5kgs, it is designed for lightweight thin film pouches, not for heavy big bags.
A: Max conveyor load 5kgs, it is designed for lightweight thin film pouches, not for heavy big bags.
Q4: Can I adjust sealing speed and seal width?
A: Sealing speed 0–12m/min adjustable, sealing width ranges from 6 to12mm for different film requirements.
A: Sealing speed 0–12m/min adjustable, sealing width ranges from 6 to12mm for different film requirements.
Q5: What temperature range does it support?
A: Temperature adjustable from 0–300℃, suitable for most PE and composite thin film bags.
A: Temperature adjustable from 0–300℃, suitable for most PE and composite thin film bags.
Q6: Is this machine easy to relocate?
A: Net weight only 39kg, compact body, easy to move and fit small production space.
A: Net weight only 39kg, compact body, easy to move and fit small production space.
