UF-620D Floor Standing Continuous Band Sealer
UF-620D floor standing continuous band sealer, heavy duty continuous sealing machine for plastic films, composite pouches. Adjustable speed and temperature, stainless steel structure, widely used in food, chemical and daily goods packaging.
Description
Pain Points for Continuous Bag Sealing
Many packaging workshops struggle with uneven sealing, weak seams and low efficiency. Manual sealing cannot keep consistent quality for mass production. Cheap sealers get rust easily and break frequently. Our UF-620D floor standing continuous band sealer solves these troubles. It delivers uniform heat sealing, stable running speed and long service life.
Suitable Industries & Bag Types
Industries: Food, snacks, spice, chemical, hardware, daily necessities Bags: Plastic film bags, composite pouches, PE/PP laminated bags
Core Advantages of UF-620D Floor Standing Continuous Band Sealer
- Floor standing heavy-duty frame, stable operation for long continuous working
- Adjustable sealing speed & temperature to match different film materials
- Stainless steel machine body, anti-rust and easy to clean
- Continuous automatic sealing, save manual labor, improve packaging output
- Compact structure, simple operation and low maintenance cost
Technical Parameters
| Item | Specification |
|---|---|
| Model | UF-620D |
| Bag Length Range | 150–600mm |
| Bag Width | 100–300mm |
| Film Width Max | 620mm |
| Packing Speed | 120–200 bags/min |
| Gas Consumption | 0.8 m³/min |
| Working Pressure | 0.6 MPa |
| Working Power | 220V, 50Hz single phase / 380V, 60Hz three phase, 5.5kW |
| Package Film | OPP/CPP, OPP/PE, PET/PE, etc. |
| Machine Size | 6875(L) × 3400(W) × 3150(H) mm |
| Net Weight | 2500 kg |
| Optional | Inflate, label, TO air exhaust, punching |
FAQ
Q1: What kind of bags can UF-620D continuous band sealer seal?
A: It works for PE, PP and composite laminated plastic pouches, widely used for food and non-food packaging.
Q2: Can I adjust sealing temperature and speed?
A: Yes. UF-620D supports independent adjustment of temperature and running speed to fit different bag thickness.
Q3: Is this machine easy to maintain?
A: Simple structure, easy to replace sealing belt and teflon tape, low maintenance cost.
Q4: Is the machine body stainless steel?
A: Yes, the main frame adopts stainless steel, suitable for wet and food grade workshop environment.
